Specifications
| Framing Size | |
|---|---|
| Rough-In Dimensions | 44.25in W x 44.25in L |
| Product Colour | |
|---|---|
| Colour | White or Black |
| Electrical Specs | |
|---|---|
| Motor | 8E92 0.69hp 1ph 240/400v 60hz 3.8/2.2amp or 8D92 0.62hp 3ph 240v 60hz 3.7amp or AGI-EC537 1hp 1ph 115/230v 60hz 5.8/9.8amp or AGI-537 1hp 1ph 230v 60hz 4.6amp or AGI-T539A 1hp 3ph 208-230/4600v 60hz 4.4-4.2/2.1amp or AGI-T540A 1hp 3ph 575v 60hz 1.8amp |
| Airflow | |
|---|---|
| CFM | 10, 910cfm @ .05 SP / 16.9cfm/W |
| Build Materials | |
|---|---|
| Mount | Galvanized Mount or Stainless Steel Mount or Standard 3-Point Mount |
| Housing | Poly |
| Blade | 3-Wing Plastic Blade, Aluminum Hub |
| Drive Type | |
|---|---|
| Drive Type | Direct Drive |
| Tags | |
|---|---|
| Tags | |
